Dyness 51.2V 10.24kwh Low Voltage Powerbox PRO Lithium Battery Pack
Package Size 55.50cm * 21.00cm * 92.80cm Package Gross Weight 120.000kg The Powerbox Pro lithium battery provides a good
Basic Info.
Model NO. | Powerbox Pro |
Size | Medium |
Capacity | 10.24kwh |
Waranty | 10 Years |
Voltage | 51.2V |
Weight | 115kg |
Transport Package | Wooden Box |
Specification | 555*210*928mm |
Trademark | Dyness |
Origin | China |
HS Code | 8507600090 |
Production Capacity | 5000 Sets/Week |
Packaging & Delivery
Package Size 55.50cm * 21.00cm * 92.80cm Package Gross Weight 120.000kgProduct Description
The Powerbox Pro lithium battery provides a good solution for residential electricity consumption. LiFePO4 chemistry battery with safety performance and longer cycle life. Four specifications for your choice which offers you various capacities to meet more of your requirements.
1. APP Monitoring
2. Various Installation
3. IP65 Protection
4. Flexible Expansion
Model | Powerbox Pro |
Battery Type | LiFePO4 |
Nominal Battery Energy | 10.24kWh |
Nominal Capacity | 200Ah |
Nominal Voltage | 51.2V |
Working Voltage | 44.8-57.6V |
Max Output Power | 5.12kW |
Max.Charge/Discharge Current | 100A |
Peak Power Charge/Discharge Current | 200A(15s) |
Depth of Discharge | 90% |
Net Weight | 103kg |
Dimension|W*D*H] | 555*210*928mm |
Charging lemp. Range | 0~55°C |
Discharging Temp. Range | -20~55°C |
Communication | CAN/RS485/RS232 |
Warranty | lOYfears |
Warranty Document Supplied | Yes |
Calendar Life[11 | a6000 Cycles |
Protection Level | IP65 |
Expansion | Up to 5 units in parallel |
Color | White |
Alarms | Overcharge/Overdischarge/Overcurrent/ Overtemperature/Short Circuit |
Monitoring & Protection | Each system has smart BMS, breaker embedded in system |
Pros | Can be used in both off-grid and hybrid setups, compact design, modular expansion |
Compatible Inverters | Victro n /SMA/Goodwe/lmeon/Solis/SAJZ Growatl/LuxpowerA/bltronic/Deye etc. |
Certification & Safety Standard | CE/UN38.3/IEC62619/IEC62040 |
